DS18B20 18B20 Temperature Sensor In Pakistan

This is the latest Digital Temperature Sensor DS18B20 from Maxim IC (but sourced from Sparkfun). The DS18B20 sensor measures temperature in degrees Celsius with 9 to 12-bit precision, -55C to 125C (+/-0.5C). Each temp sensor has a unique 64-bit serial number programmed into it which allows for a huge number of sensors to be used on one data bus. The best Arduino temperature sensor is a wonderful part that is the cornerstone of many data-logging and temperature control projects.


Specification of DS18B20 18B20 Temperature Sensor:

  1. Model: DS18B20
  2. Operating Voltage (VDC): 3 ~ 5.5
  3. Operating Temperature (°C): -55 to 125
  4. Usage: Temperature Sensor
  5. Material: Metal
  6. Type: Temperature Sensor
  7. Output: Switching Transducer
  8. Theory: Hall Sensor
  9. is_customized: Yes

Feature of 18B20 Temperature Sensor For Arduino:

  • The unique 1-Wire® interface requires only one port pin for communication.
  • Each device has a unique 64-bit serial code stored in an onboard ROM.
  • Multidrop capability simplifies distributed temperature sensing applications.
  • Requires no external components.
  • It can be powered from the data line. The power supply range is 3.0V to 5.5V.
  • Measures temperatures from –55°C to +125°C (–67°F to +257°F).
  • ±0.5°C accuracy from –10°C to +85°C.
  • Thermometer resolution is user-selectable from 9 to 12 bits.
  • Converts temperature to 12-bit digital word in 750ms (max.).
  • User-definable nonvolatile (NV) alarm settings.
  • The alarm search command identifies and addresses devices whose temperature is outside of programmed limits (temperature alarm condition).
  • Applications include thermostatic controls, industrial systems, consumer products, thermometers, or any thermally sensitive system.

Package Include:

  • 1 x DS18B20 18B20 Temperature Sensor In Pakistan
