Arduino Compatible USB Host Shield In Pakistan
The Arduino Compatible USB Host Shield is based on the MAX3421E, which is a USB peripheral/host controller containing the digital logic and analog circuitry necessary to implement a full-speed USB peripheral or a full-/low-speed host compliant to USB specification rev 2.0. it is compatible with more Arduinos – not only UNO and Duemilanove but also Mega and Mega 2560 work with a Standard variant of this shield out of the box. No more SPI re-wiring and code modifications – just solder included stackable connectors (2×3 ICSP connector’s female side should be facing down), plug and play! Using Arduino Compatible USB HOST function, let your Arduino communicate with other USB devices, and supports USB HUB function.USB Host shield adds USB Host capabilities to the Arduino board.
₨2400
Specification of Arduino Compatible USB Host Shield:
- Model: 6937
- Color: Blue
-
Material: FR4
-
Ports: USB
-
Dimensions: 53mm x 50 (LxW) mm
-
Works with standard (dual 5/3.3V) and 3.3V-only (for example, Arduino Pro) boards.
-
Operates over the extended -40°C to +85°C temperature range
-
Complies with USB Specification Revision 2.0 (Full-Speed 12Mbps Peripheral, Full-/Low-Speed 12Mbps/1.5Mbps Host)
-
Supports HID devices, such as keyboards, mice, joysticks, etc.
-
Compatible with Mass storage devices, such as USB sticks, memory card readers, external hard drives (FAT32 Type File System – Arduino Mega only).
Package Include:
- 1 x Arduino Compatible USB Host Shield In Pakistan
