3 wire DC 0 to 30V DC Red LED digital voltmeter
Range DC 0-30V, 3-wire products Universal, to break the routine voltmeter, is the latest design, can work directly in 5V, 9V, 12V, 24V and other circuits, without regulation. With three wiring, easy access to car /battery car / motorcycle-car line, with reverse polarity protection, line reversal will not burn. For monitoring the battery voltage, battery voltage state to grasp, it can also be used for other products voltage measurement purposes.
₨380
DC Voltmeter: 0-200V. Power supply: DC4-30V Measuring range: 0-200V. Measurement accuracy: ±0.1% Refresh rate: about 200ms Display: 0.56 “digital tube Color: red,
- DC Voltmeter: 0-30V.
- Power supply: DC4-30V
- Measuring range: 0-30V.
- Measurement accuracy: ±0.1%
- Refresh rate: about 200ms
- Display: 0.56 “digital tube
- Color: Red
- Operating current: Less than 8mA
- Operating temperature: -10°C to 65°C
- Input impedance:100K
- Overall dimension: 48*29*26mm
- Display LED color – Red
Wiring instructions:
White Line: Measuring DC 0-30V
Red line: Power Supply DC 4-30V
Black lines: Common negative
Range DC 0-30V, 3-wire products Universal, to break the routine voltmeter, is the latest design, can work directly in 5V, 9V, 12V, 24V and other circuits, without regulation. With three wiring, easy access to car /battery car / motorcycle-car line, with reverse polarity protection, line reversal will not burn. For monitoring the battery voltage, battery voltage state to grasp, it can also be used for other products voltage measurement purposes.
Based on 0 reviews
Be the first to review “3 wire DC 0 to 30V DC Red LED digital voltmeter”
